DescriptionEvery electronics designer eventually encounters a project where standard 40V or 60V components are instantly destroyed by the circuit’s high-voltage rails. The MMBTA92 High Voltage PNP Transistor is the highly popular, surface-mount evolution of the classic MPSA92. It is designed specifically to provide excellent switching speeds, reliable signal amplification, and robust isolation for demanding high-voltage, high-side applications.NameTypesImagePriceAdd Link2SA733PNP350Add to Basket2SC1623NPN400Add to Basket2SC945NPN350Add to BasketA1015PNP350Add to BasketBC807PNP400Add to BasketBC817NPN300Add to BasketC1815NPN400Add to BasketMMBT2222ANPN350Add to BasketMMBT2907PNP400Add to BasketMMBT3904NPN350Add to BasketMMBT3906PNP350Add to BasketMMBT4403PNP400Add to BasketMMBT5401PNP350Add to BasketMMBT5551NPN350Add to BasketMMBTA42NPN400Add to BasketMMBTA44NPN350Add to BasketMMBTA92PNP350Add to BasketS8050NPN350Add to BasketS8550PNP350Add to BasketS9012PNP350Add to BasketS9013NPN350Add to BasketS9014NPN350Add to BasketS9015PNP350Add to BasketS9018NPN350Add to BasketSI2305P-Channel400Add to BasketExtreme -300V Blocking PowerWhile standard small-signal PNP transistors like the 3906 max out around -40V, the MMBTA92 comfortably blocks and switches voltages up to an impressive -300V. This makes it an exceptional choice for bridging the gap between delicate low-voltage controllers and high-voltage peripherals. Use it as a reliable high-side switch to drive Nixie tubes, neon indicators, piezo drivers, or feedback loops in switch-mode power supplies.The Perfect Complementary PairFor engineers designing high-voltage audio amplifiers or discrete push-pull driver stages, the MMBTA92 is the exact PNP complement to the NPN MMBTA44. Using these two transistors together allows you to build highly efficient, symmetrical high-voltage driver arrays in a very small physical footprint.Compact SOT-23 FootprintHistorically, high-voltage transistors required bulky through-hole packages to prevent arcing and manage heat. The SOT-23 surface-mount package brings this heavy-lifting capability to modern, space-constrained PCBs. Featuring the industry-standard top mark 2D, this component is easy to identify during manual prototyping, inventory management, or automated pick-and-place assembly.Key FeaturesMassive Voltage Overhead: The -300V rating allows for safe operation in telecommunications, display driving, and mains-referenced circuits.High-Side Routing: As a PNP device, it is perfect for routing power directly from high-voltage positive rails.Miniature Footprint: The SOT-23 SMD package optimizes valuable PCB real estate while maintaining excellent thermal and electrical stability.Technical SpecificationsTransistor Polarity: PNP BJTCollector-Emitter Voltage (VCEO): -300V MaximumCollector-Base Voltage (VCBO): -300V MaximumEmitter-Base Voltage (VEBO): -5V MaximumContinuous Collector Current (IC): -500mAPower Dissipation (PD): 350mWDC Current Gain (hFE): 25 to 40 (varies by collector current)Package Type: SOT-23 (Surface Mount)Common Top Marking Code: 2DIdeal ApplicationsDisplay Drivers: High-side multiplexing for high-voltage Nixie tubes, neon lamps, and vacuum fluorescent displays (VFDs).Power Supply Design: Operating within the feedback and regulation loops of offline Switch-Mode Power Supplies (SMPS).Telecommunications: Acting as a reliable switch or amplifier in traditional telephony and high-voltage communication line interfaces.Electronics Repair: Replacing faulty 2D-marked high-voltage PNP transistors in commercial lighting ballasts, audio amplifiers, and power adapters.
